Building a Voice AI Stack That Balances Power With Flexibility

Most voice AI platforms either lock developers into rigid templates or require stitching together disjointed AI, telecom, and infrastructure components by hand. SignalWire’s voice AI stack is built on the same telephony core that powers FreeSWITCH and Call Fabric, combining low-latency media, programmable call control, and AI orchestration into a single environment. This article explains the principles behind that stack, including focusing on leading AI models, isolating sensitive data with traditional voice menu techniques, making AI agents feel as straightforward to build as web apps, and designing for extremely low latency at scale.

I've been working in the telecommunications industry for

20+ years, and my life's work has revolved around

transforming telecom to software and making it

programmable.

I have been working on making voice bots that don't suck

since they sucked. But I'd like to think we made them suck

a bit less and made them more accessible to the world.

Before FreeSWITCH, IVRs and voicemail used to cost

100k for a physical server that was converted to pure

software.

Like the Internet, when it was new to the general public, as

soon as LLMs that could be consumed at scale over a

reliable API appeared, all of its use cases were almost

immediately obvious. I think anyone can conclude that with an LLM generating human language, you can wire it up to text-to-speech and speech-to-text or to an existing chat

interface.

My thesis on approaching this technology started

with the hardest thing, voice, as making a chat-based

interface is almost trivial in comparison. I have a few key

tenets that I worked with initially.

1) Focus on the leading technology (OpenAI)

Like with computers, the Internet, and other inflection point

changes, you can presume that the core technology will

eventually reach equilibrium and that business cases for

using the technology will be the main differentiator. So, rather than an early focus on the model, I wanted to focus

on the use case (allowing developers to build digital employees). OpenAI has several things about how its

APIS work that give a low-level developer more power to

exploit and simplify for end-user developers.

2) Leverage the AI in a way that limits its ability

to be exposed to sensitive data by combining it with

existing voice menu technology

Our stack is designed as an extension of a more massive stack for general scalable telecom services. The AI stack can actually call into a traditional voice menu to collect sensitive info from the user. Then, it can save

a meta-data token and just tell the AI that the data was

collected without it ever actually interacting with it.

3) Create an environment for developers that is as easy to use as the Web

Our stack is inspired by UNIX and the Web and is, in

essence, an extension of those concepts. The AI Agent you create could be considered a new way

to look at web forms in a way that allows you to talk to

them. Its prompts tell it how to talk to the user and collect

info, then use functions to post that data to your servers,

where you can feed information back and modify its

behavior in several ways. Because our AI stack is one

method in an even larger telephony stack, it has all the

powers of its parent platform to work with to transfer calls,

send SMS, and scale to any number of concurrent calls

that can be over phone lines, SIP (VOIP), WebRTC and

UCaaS applications on our platform.

4) Be the lowest latency period

Since the first experiment, I have been working on designs

to eliminate latency. I have developed several techniques

that are solved mostly by ingenuity and deep knowledge of

C, and I have one of the most powerful communications

platforms on the planet under my belt.

I know the new GPT-4o is trying to short-circuit the whole thing by doing some of the work in a mobile phone and has models that can ingest audio, but they have a billion dollars to burn, so I would expect nothing less. Meanwhile, I think we have a system that actually does

useful things and responds at a speed where you might

even consider slowing it down in some cases (which is

configurable). We are able to use almost any modern TTS

natively and minimize latency at all points of orchestration.

Built to scale

Our AI orchestrator is just another cog in a proven

powerful engine so applications can

scale forever with the horizontal implementation of its

parent platform.

Conversational experience will always be a challenge (it

still is with real humans, after all) but I think we offer such a

wide array of params and ways to approach it that we will

evolve further and further.

Vertically focused

We have an elaborate system called SignalWire

AI Gateway (SWAIG) that is built on top of the Agent framework

and allows deep integration points that are the building

blocks to implement drop-in skills. We have several demos

for things like booking a restaurant, ordering flowers, cable technician, MFA bot, and more. Rather

than focusing on training models, we strive to leverage the

least training possible to build working applications

quickly. We have a system in the works that will allow live

vectorization of arbitrary documents to provide on-demand

I think most people fake their results and we have a strict rule against that.

Realistic in Scope

This is key. The expectations that are often set by how cool AI is. Sometimes, it causes people to make the wrong assumptions.

This is nothing new as we, as engineers, often refer to the

National Park vs Bird xkcd comic.

We believe that systems using digital employees created

with our stack can do a lot of things immediately and even

more as the technology progresses:

• Sorting calls for humans.

• Gathering information ahead vs. keeping customers on hold.

• Being voicemail without being voicemail.

• Acting as personal assistants.

What's different from others?

I've seen a few of the other AI stacks, and while we have some things in common, I think our

approach has some key differentiated elements.

Part of a fully Programmable Unified Communications stack.
The AI agent stack is tethered to a horizontally scaling

UCaaS, CCaaS, CPaaS platform. You can access the

agents from SIP, PSTN, WebRTC UCaaS applications not

limiting the experience to over the phone.

Scaling Complexity

As your needs evolve, you can deliver dynamic content to

generate on-demand agents or build out SWAIG services

to allow your agent to get more and more technically

capable.

Context Switching

The agent can be dynamically altered mid-conversation to

change its focus or core prompting so you can have a

general Agent who suddenly becomes completely focused

on finding you a good movie to watch and then suddenly

able to book a restaurant reservation. There is also a

"steps" mode that will force the agent down a series of

pre-determined steps where its core mission is updated as

it completes each one. This could be combined with

context switching to do a more thorough job.

Sliding Window

Rather than continually posting the entire conversation to

the AI, a sliding window can be defined to limit the

conversation to a certain number of turns. I have an

example where it's wired into an infocom text adventure

from the 80's where it gets you to say what you want

to do and feeds it to the game (no need to save the whole

conversation).

A simple digital employee can be created as a single

JSON file that can be hosted on our systems or delivered

over webhook.

Multiple Voices, Languages and Fillers

An agent can have a single muti-lingual voice or different voices for each language and can switch between them just by asking it to. Each language can have optional fillers

which are a list of phrases to indicate the agent is looking

something up where the remote service may contribute

enough to latency that it has to say, "ok, one second" or

"hold on." For extreme cases like one example where you order flowers and it uses an AI image generator to text you

a picture of the flowers you describe, a sound file can be

played like pencil scribbling or keyboard typing.

Media Files

The agent can play a looping background sound like

people talking in a coffee shop or kids playing in a park or

a busy office to add to the experience. Via SWAIG the

agent can be instructed to play a file as part of the

conversation. For example, I had a "duck debugger" who offers to

help you find your problem and pretends to ask a rubber

duck who quacks in response to your questions.

Video

If the agent is called over a video enabled line, it can use a series of mp4

files to simulate a state of idle, paying attention, and

talking. If it's instructed to play a video file, in place of its

avatar, it can stream the video to the remote user. I

have plans to eventually have it snapshot your inbound

video and "see" what is in the picture.

Advanced Barge Cutoff / Adjustable Latency

To pursue the best conversational experience, the agent

defaults to a behavior where if you start talking over each other, not only does it stop and let you win, but it also combines everything you are saying into a single turn and

removes any early responses. So if you are talking to the

agent with many pauses in your speech pattern and the

agent starts answering too soon, just by continuing to talk,

it will adjust to the new combined utterances and form a

completely new response.

Built-in Post-Prompting and full logging and debugging

A post-prompt can be defined to do a final action such as

summarizing the conversation, formulating a pizza order

into a json blob, etc. Special SWAIG functions are

available at the beginning and end of the conversation to

take a leading or final action in particular cases.

Debugging webhooks can be defined to obtain mid-conversation details, so you know what's going on as it

works.

Unified support for ASR/TTS

All of our supported ASR/TTS interfaces are available to the AI and the normal voice menu system, so you can mix and match advanced AI portions of the conversation with classic voice menu techniques. Currently, we support Elevenlabs, Google, PlayHT, and Amazon Polly, and adding more is trivial. Any new ones appear in all

aspects of the platform.

Persistent Conversation Tracking

Several features enable the agent to be seeded with information from a previous call so you can provide the sense that it knows what happened in previous conversations.

Ability to receive chat or SMS during the conversation

Messages can be sent to the agent while you are talking

to it on the phone, allowing you to chat or SMS with it while

you are talking to it, for cases like sending your email

without reading it out loud or getting helpful links

from the agent. The Santa Claus example asks you

what you want for Christmas and then sends you links at

Amazon. The flowers example asks you what flowers you

want and who to send them to and texts them a custom AI-generated picture of flowers based on your input.

SWAIG

The SignalWire AI Gateway is a native interface that is immeasurably flexible as part of our AI stack. It extends the basic 'functions' feature from the language model into a system that allows the developer to create solutions with evolving complexity, starting with static file and template-driven data expansion and moving on to full remote

custom webhooks.

LINKS

Github repo of examples

Developer Docs

Frequently asked questions

What does “a voice AI stack that balances power with flexibility” mean?

SignalWire’s stack is designed to give low-level developers full control over voice, media, and AI behavior without forcing them into a rigid template system. It exposes powerful primitives for call control, speech, and AI orchestration while still letting teams choose models, prompts, transport, and integrations that fit their own applications instead of a single canned pattern.

How does the stack handle sensitive data in voice AI applications?

The stack uses traditional voice menu techniques alongside AI so that sensitive information, such as payment or identity data, can be collected in a controlled IVR flow while the AI only receives meta-data about what was collected. This lets developers keep sensitive values out of the model context while still allowing the AI agent to drive the conversation and business logic.

Why is low latency such a big focus in this voice AI stack?

Natural conversations break down when responses lag, so the stack is engineered to minimize latency across every layer, from media handling and telephony to AI calls and orchestration. By combining a highly optimized telecom core with efficient AI integration patterns, the system can respond quickly enough that developers sometimes slow it down intentionally for a more human pacing.

How is this stack different from other voice AI platforms?

Unlike platforms that bolt AI onto a separate CPaaS layer, SignalWire’s AI agents run inside a fully programmable communications platform with direct access to SIP, PSTN, WebRTC, and UCaaS surfaces. That means the same stack that powers the AI also handles scaling, transport, routing, and vertical skills through components like SignalWire AI Gateway (SWAIG), rather than depending on third-party glue or ad hoc integrations.

What kinds of applications can developers build on this stack today?

Developers can build digital employees that sort and triage calls for humans, gather information before escalating to agents, replace static voicemail with conversational intake, act as personal assistants, and plug into vertical use cases like bookings, support workflows, and account tasks using SWAIG skills, SWML flows, and the underlying Call Fabric platform.
